Skiff Workshop Cage Bearings - Pivot: 1/4" - Ceramic Bearings: 1/16" - 13 ball

Thumbnail Filmstrip of Skiff Workshop Cage Bearings - Pivot: 1/4" - Ceramic Bearings: 1/16" - 13 ball Images

    Purchase Skiff Workshop Cage Bearings - Pivot: 1/4" - Ceramic Bearings: 1/16" - 13 ball

    Skiff Workshop Cage Bearings - Pivot: 1/4" - Ceramic Bearings: 1/16" - 13 ball

    Manufacturer SKU: AC-SKF-5-14-13-116

    $13.00

    29 available for purchase

    Skiff Workshop Cage Bearings - Pivot: 1/4" - Ceramic Bearings: 1/16" - 13 ball

    These cage bearings are compatible with knives like the GiantMouse Grand, Hinderer XM-18, Project X, and Elkipse. Click Compatibility tab for more info.

    PLEASE NOTE: Modifying your knife may void the OEM warranty on your knife. Please check the manufacturer's warranty for the knife that you will be modifying. By purchasing these cage bearings, you acknowledge this possibility, and that LynchNW or SKiff Workshop are not liable for any damage to your folding knife that may occur during installation of these bearings.

    Cage bearings that allow more balls to be placed around the knife pivot than standard cage bearings. Which provides more support for the blade and decreasing stress on each ball. The ceramic balls are captured in the disc but are still free floating to prevent binding.

    Includes Grade 5 ceramic bearings pre-installed.

    • 22% increased blade support over caged bearings of same size
    • Improved ball pathing around pivot
    • Less pivot screw tightening required
    • CNC machined from solid phosphor bronze

    Dimensions

    Inner Diameter
    Outer Diameter
    Thickness Ball
    0.252" 0.420" 0.050" 0.0625
    6.4mm 10.668mm 1.27mm 1.587mm












    Ordering details

    • One set equals two individual cage bearings

    Specifications

    Additional Installation and Maintenance Info from Skiff Workshop:

    The amount of torque needed for each knife's pivot when installing these bearings  is entirely by feel. You should start off lightly and test the blade, then tighten a little more, retest the blade. Repeat that until you are happy with the action. If you are using the 8mm x 1/16" bearings then you would need less torque when tightening the pivot since there are more balls to spread the load.

    For cleaning, you can use some light ammonia free de-greaser. Simple Green or even Windex should be fine. If you use a de-greaser then you should apply a drop of oil to each cage when installing. You can use compressed air to clean out the bearings. If the compressed air is too strong you may need to push some of the balls back to center if they become stuck on one side.

    Compatibility

    Bearing Compatibility

    The below knives have been found to work with this bearing.

    Click here to view the full Skiff Workshop compatibility chart.

    Alliance Designs
    • Mini Slim Pickens
    American Blade Works
    • Model 1 V5/V6
    • Model 2 (Titanium)
    Arcane Design
    • Creature
    Artisan
    • Proponent (full size)
    Berg Blades
    • Iron Wolf
    Bestech
    • Bandit (Kaviso Exclusive)
    • Falko
    • Kendo (Ti)
    Cheburkov
    • Frieze
    • Small Strizh (bearings)
    Curtiss Custom Knives
    • F3
    Demko
    • AD-20 Titanium (older)
    Emerson
    • Sheepdog
    GiantMouse
    • ACE Grand
    Heretic
    • Pariah
    • Wraith
    Hinderer
    • Eklipse Triway (3rd Gen)*
    • Halftrack*
    • Jurassic Triway*
    • Maximus
    • Project X
    • XM-18 3" Triway
    • XM-18 3.5" Triway
    Holt
    • Haptic
    • Morpheus
    • Specter
    Kizer
    • Intrepid
    • Mini Paragon
    • Sheepdog
    Krudo
    • Dao LTE
    • Vice
    Les George
    • VECP V3 Morph
    Rike
    • RK801G
    Ruike
    • P128
    Sharp By Design
    • Apex
    • Derecho
    • Typhoon EVO
    • Void
    SOG
    • Kiku XR
    Spyderco
    • Dice
    • Domino
    • Southard
    SRM
    • 9008
    Terzuola (Drop)
    • ATCF
    TwoSun
    • Bowhead
    • TS80
    • TS103
    • TS136
    • TS137
    • TS138
    • TS159
    • TS180
    • TS190
    • TS195
    • TS196
    • TS219
    • TS261
    • TS361
    Vero Engineering
    • Impulse
    • Isotope
    • Synapse XL V3
    Viper Knives
    • Italo
    WE
    • 037
    • Syncro
